Amprobe’s AMP-300 Series True-RMS Clamp Meters offer a complete range of measuring functions for modern industrial environments, motor testing and HVAC applications. All models feature True-RMS sensing, low pass filters and fast response processors for quick, error-free measurements. The Amp-Tip function allows for precise measurement of current down to the tenth of an Amp, and a third input jack enables motor rotation and 3-phase sequence testing.
- True RMS
- Motor Testing Capabilities: Motor rotation / 3 Phase Sequence Testing / Inrush current monitoring during motor start up
- HVAC Features
- Amp-Trip Function
- Low Pass Filter for variable frequency drives
- Safety Rating: CATIII 600V (AMP310, AMP320) CATIV 600V / CAT III 1000V (AMP330)
- Free ACT Calibration Certificate
| Segments | Motor Testing Clamps |
|---|---|
| Safety Rate | CAT IV 600 V |
| Max Current | 1000 A |
| Voltage AC (high) | 1000 V |
| Voltage DC (high) | 1000 V |
| Clamp Opening | 51mm |
| Features | Capacitance, Continuity, Datahold, Diode Test, Frequency Measurement, Infrared Thermometer, Micro Amp, Non-contact Voltage, Peak Hold, Phase Rotation Indication, Resistance, True RMS |
| DC Current (high) | 1000 A |
Click on the link below to download the data sheet
