HIKMICRO M20W handheld thermography camera is specially designed for professional inspections. It’s equipped with a 256×192 resolution thermal detector and an 8MP resolution visual camera.
The high resolution 3.5-inch touch screen displays crisp, clear images and streamlines camera operations.
Imaging modes include thermal, visual, picture in a picture of the optical and thermal view, and fusion of both channels. The M20 quickly identifies potential faults, quantifies the impact with accurate temperature measurement, provides detailed documentation to complete your inspections efficiently.
| Hikmicro M20/M20W Comparison | ||
|---|---|---|
| M20W (Wide-angle optics) | M20 Standard Model | |
| Focal Length | 3.6 mm | 6.9mm |
| F-number | F1.0 | F1.0 |
| Field of View (FOV) | 50° × 37.2° | 25° × 18.8° |
| Spatial Resolution (IFOV) | 3.33 mrad | 1.74mrad |
| Focus Mode | Focus Free | Manual |
| Min. Focus Distance | 0.5 m (1.64 ft) | 0.1 m (0.33 ft) |
*Important Calibration Information:
This instrument comes complete with the manufacturer’s calibration certificate. Please be aware that these certificates are generic and may also be time lapsed.[Text Wrapping Break]If you would prefer a personalised full traceable calibration certificate applied to the equipment before dispatch, then please select this option from the drop-down menu above, an additional calibration charge will apply.
Hikmicro M20W Comes Supplied With:
- Hikmicro M20W Camera
- International Use Plugs (US/EU/UK/AU) for Power Supply
- Power Supply for Battery Charger
- USB 2.0 A to USB Type-C Cable
- Two-bay Battery Charger
- 2 x Battery
- Wrist Strap
- Carry Case
- Quick Start Guide
- Calibration Certificate
Key Features:
- High sensitivity thermal module with 256 × 192 resolution
- Supports multiple palettes
- High quality optical module with 8 MP resolution
- Bi-spectrum image fusion, picture-in-picture preview
- Wide temperature measurement range: -20°C to 550°C
- High temperature measurement accuracy: Max. (± 2°C/3.6°F, ± 2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
- High-calibre 640 × 480 resolution 3.5” LCD touch display
- Long-distance laser light supplement for thermography targets
- LED light supplement makes the device a torch in required scenarios
- Supports 1×, 2×, 4× and 8× digital continuous zoom
- Support remote album access, download and quick report with APP.
HIKMICRO Viewer App
Conveniently share images and reports, connect the HIKMICRO Viewer App via Wi-Fi to transfer photos or videos from camera to mobile device. Analyze, share images, and generate reports in real-time on-site.
