KEY BENEFITS
Large colour dot matrix screen
Established easy to use interface with one rotary dial and four function keys
Two high current loop options: 25A 0.001 Ohm resolution & 6A 0.01 Ohm resolution
Two low current loop options: 3 wire & 2 wire
EVSE loop option
EVSE 6 mA DC ramp and tripping time test
Insulation test function with PI
Surge protesction device test
Comprehensive RCD function including type EV & B and variable RCD test
Earth resistance 3 & 2 wire options
PAT function including download
G7 test leads
Max Zs tables for current and old standards
Phase rotation
Advanced memory
KEY FEATURES
Simultaneous display of L-N, L-N, L-E voltage (TRMS)
Three modes of starting a test: single press of the test button, continuous testing and by test button in the test probe
Help disolay
Advanced memory – assigns DB, circuit no. ad type of test i.e. Zs or Ze
Two continuity tests 200mA & 15mA
55V loop test capability – suitable for 110V CTE systems
Padded neck strap
Supplied with G7 test leads and additional probe incorporating a test button
Tests Type AC, ACS, A, AS, F, B, BS & EV
UC – contact voltage test
Touch volatge pad with selectable limits
Heavy duty canvas carry case with exrta room for you testing accesssories
The KT66DL has a lid to further protect your instrument. It easily folds under the instrument when in use
INCLUDES
ACC064SP G7 test lead with remote test button
ACC065 G7 Test lead set
8 x AA Batteries
Instruction Manual
End of line Calibration Certificate
KAMP 12 Mains lead
Test lead pouch
Soft carry case
OPTIONAL
ACCESKIT – Earth Spikes
PATADAPTOR1 – Pat adaptor for PAT testing
For further information on the KT66DL click on the link below
KT66DL DATA SHEET
